DEPRAG Turbine powered pneumatic motors

Energy-efficient speed-regulated turbine-powered Air motors. These motors are 40% more efficient than vane motors and eliminate uncontrolled high speed and high air consumption under low or no load conditions.

These motors are available in 8 speeds from 70 to 2880rpm and the power output can be switched between 1.5, 3.0 or 4.5kW

The perfect, efficient pneumatic drive for pumps, mixers and conveyors.

Significant advantages of our turbine compressed air motors compare to vane motors:

• 40% more efficient
• Lubrication is not required
• Longer Lifetime compared to vane and piston motors
• Integrated Speed Governor
  • reduces air consumption when the motor is under low load or no load conditions
  • prevents damage to pumps, drills, mixers, conveyors etc because the idle speed is close to the loaded speed
  • more constant speed under load
• Large range of integrated gearing
  • select from 8 loaded speeds from 70rpm upto 3880rpm
• Maximum output torque of 409Nm
• ATEX approved for use in potentially explosive environments
• Fully Sealed for use in wet environments
• USDA-H1 Grease for food industry
• Rust proof housing for wet areas and wash down
• Adjustable Power of 1.5, 3 and 4.5kW

Please NOTE:

• Turbine motors are not available as reversible motors so the turn direction must be specified with an order
• Air supply must be very clean and water free (dew point of -20 DegC) or the air supply needs to be pre-heated otherwise the motor will be damaged
• Due to the efficiency of turbine motors, the exhaust air will be extremely cold, so it must be directed away from people or sensitive equipment.  Ice will form outside of the motor or exhaust pipes, especially if used for long periods of time under full load conditions.
